Total Laser Power：RGB - 22,000mW
Diode-637nm：>6000mW
Diode-520nm：>8000mW
Diode-445nm：>8000mw
Beam diameter：5.5mm
Beam divergence：1.1mrad(full angle)
Modulation：>100KHz Analog
Scanner：PT-A30
AC power：100-240V 50/60Hz
Protection rating：IP 52
Size： L406 * W255 * H197mm
Weight：23.65kg
Class IV laser products
Retail Price：
Description：
- Laser Module：Pure diodes, longer lifetime, higher reliability. Low divergence < 1.1 mrad (full angle).
- Scanner：PT-A30 wide angle, New detecting technique, Large scan angle, Excellent overload capacity and linearity.
- Laser Case：New dust free design, efficient cooling-Heatsink area covers 40% of the laser case area. Slide cover for easy/quick beam alignment.
- Safety：Pure ILDA control board, Safety key switch, Time delay for laser shooting, Emergence stop box ( Time delay ), Slide cover for beam aperture, Shutter, Scan-fail protection, Auto Power-Cut etc.
Show Results：
